Ubiquiti airFiber 5U Price in Pakistan
Why Choose the Ubiquiti airFiber 5U?
The Ubiquiti airFiber 5U (AF-5U) is a professional 5GHz point-to-point wireless backhaul radio designed for ISPs, WISPs, telecom operators, enterprises, and network professionals that need high-capacity long-distance connectivity.
The airFiber 5U is part of Ubiquiti’s airFiber PtP family and is specifically designed for high-band 5GHz deployments. Ubiquiti specifies 1.2+ Gbps maximum throughput, 100+ km maximum range, GPS radio-frame synchronization, and more than one million packets per second under specified conditions.
Its combination of long-range wireless connectivity, Gigabit Ethernet, GPS synchronization, advanced modulation, and AES encryption makes the airFiber 5U suitable for demanding wireless backhaul applications.
Ubiquiti airFiber 5U Price in Pakistan
The Ubiquiti airFiber 5U is designed for organizations that need to establish high-speed wireless connections between two geographically separated locations.
It operates in the 5GHz high-band spectrum, with supported frequency ranges varying according to the regulatory region. Ubiquiti’s specifications list 5725–5850 MHz for FCC regions, 5725–5875 MHz for ETSI regions, and up to 5725–6200 MHz in other regions.
The AF-5U can provide a practical alternative to physical cabling for tower-to-tower, building-to-building, and remote-site network connections where fiber installation is difficult or expensive.
Ubiquiti airFiber 5U Features
Key Features
- Ubiquiti airFiber 5U
- Model: AF-5U
- 5GHz High-Band Wireless Backhaul
- Point-to-Point (PtP) Connectivity
- Up to 1.2+ Gbps Throughput
- Up to 100+ km Maximum Range
- GPS Radio Frame Synchronization
- Up to 1024QAM Modulation
- 10/20/30/40/50 MHz Channel Bandwidth
- 128-Bit AES Encryption
- 1 × Gigabit Ethernet Data Port
- 1 × 10/100 Mbps Management Port
- RJ-12 Alignment Tone Port
- Passive PoE Support
- 50V 1.2A Gigabit PoE Adapter
- Automatic Transmit Power Control (ATPC)
- 1+ Million Packets Per Second
- Low-Latency Wireless Backhaul
- Pole Mount Kit
- Outdoor Deployment
- Operating Temperature: -40°C to 55°C
- Dual-Polarized Wireless Operation
These specifications are based on Ubiquiti’s published airFiber AF-5/AF-5U documentation.
Ubiquiti airFiber 5U Specifications
| Specification |
Details |
| Model |
Ubiquiti airFiber AF-5U |
| Product Type |
5GHz PtP Wireless Backhaul Radio |
| Frequency |
5GHz High Band |
| Maximum Throughput |
1.2+ Gbps |
| Maximum Range |
100+ km |
| Modulation |
Up to 1024QAM MIMO |
| Channel Bandwidth |
10/20/30/40/50 MHz |
| Encryption |
128-Bit AES |
| Data Interface |
1 × 10/100/1000 Ethernet |
| Management Interface |
1 × 10/100 Ethernet |
| Auxiliary Port |
RJ-12 Alignment Tone |
| Synchronization |
GPS |
| Power Method |
Passive PoE |
| Power Supply |
50V 1.2A Gigabit PoE Adapter |
| Maximum Power Consumption |
40W |
| Packets Per Second |
1+ Million |
| Operating Temperature |
-40°C to 55°C |
| Mounting |
Pole Mount Kit |
| Wind Survivability |
Up to 200 km/h |
| Uplink/Downlink Ratio |
50% Fixed |
Why Is the Ubiquiti airFiber 5U Ideal for Wireless Backhaul?
The airFiber 5U is built for professional wireless backhaul rather than ordinary Wi-Fi access.
Its high-band 5GHz operation, high throughput, long-distance capability, and GPS synchronization make it suitable for creating dedicated links between network sites.
It can be used to connect:
- ISP Towers
- Telecom Sites
- Corporate Buildings
- Remote Offices
- Data Centers
- CCTV Locations
- Network Distribution Points
- Rural Broadband Sites
- Campus Networks
- Wireless ISP Infrastructure
For organizations expanding their network infrastructure, a high-capacity PtP radio can provide connectivity between locations without requiring a direct physical fiber connection.
Ubiquiti airFiber 5U Long-Range Connectivity
One of the major advantages of the Ubiquiti airFiber 5U is its long-distance wireless capability.
Ubiquiti specifies a maximum range of 100+ km, although real-world range depends on antenna configuration, line of sight, terrain, interference, regulatory restrictions, weather, channel bandwidth, and link design.
For professional deployments, proper antenna alignment and a clear Fresnel zone are important for achieving reliable performance over long distances.
Ubiquiti airFiber 5U High-Speed Performance
The AF-5U supports 1.2+ Gbps maximum throughput under the conditions specified by Ubiquiti.
Its wireless platform supports multiple modulation levels, including 1024QAM, 256QAM, 64QAM, 16QAM, and QPSK, allowing the system to adapt to changing link conditions.
This makes the airFiber 5U suitable for applications that require significantly more bandwidth than basic wireless networking equipment can provide.
Ubiquiti airFiber 5U GPS Synchronization
The airFiber 5U uses GPS-based radio frame synchronization.
GPS synchronization is particularly useful when deploying professional wireless infrastructure because it helps coordinate transmission timing and can improve network planning in multi-radio environments.
The official specifications also list GPS synchronization as part of the AF-5U wireless system.
Ubiquiti airFiber 5U Security
Security is important when wireless infrastructure carries business or ISP traffic.
The airFiber 5U supports 128-bit AES encryption, helping protect wireless communications between connected endpoints.
This makes the AF-5U suitable for professional network environments where wireless backhaul links carry sensitive business or customer traffic.
Ubiquiti airFiber 5U Ethernet and PoE
The AF-5U provides a 10/100/1000 Ethernet data port for high-speed network connectivity and a separate 10/100 Mbps management port.
It uses passive Power over Ethernet and comes with a 50V 1.2A Gigabit PoE adapter. Ubiquiti specifies maximum power consumption of approximately 40W.
This simplifies installation by allowing the network connection and power delivery to be handled through the appropriate Ethernet/PoE infrastructure.
Ubiquiti airFiber 5U Outdoor Design
The airFiber 5U is designed for outdoor wireless deployments and can operate between -40°C and 55°C.
Its hardware is designed to withstand demanding outdoor conditions, with Ubiquiti specifying wind survivability up to 200 km/h for the AF-5/AF-5U hardware.
This makes it appropriate for tower, rooftop, and other outdoor wireless backhaul installations.
Where Can the Ubiquiti airFiber 5U Be Used?
The Ubiquiti airFiber 5U is ideal for:
- Wireless Internet Service Providers
- Internet Service Providers
- Telecom Companies
- Enterprise Networks
- Long-Distance Wireless Links
- Tower-to-Tower Connectivity
- Building-to-Building Links
- CCTV Backhaul
- Rural Broadband
- Campus Networking
- Remote Office Connectivity
- Network Aggregation
- ISP Backhaul Infrastructure
Why Buy the Ubiquiti airFiber 5U?
The Ubiquiti airFiber 5U offers several advantages:
- High-capacity 5GHz wireless backhaul
- Up to 1.2+ Gbps throughput
- Up to 100+ km specified range
- High-band 5GHz operation
- GPS synchronization
- Up to 1024QAM modulation
- 128-bit AES encryption
- Gigabit Ethernet connectivity
- Passive PoE support
- Automatic Transmit Power Control
- 1+ million packets per second
- Professional outdoor construction
- Long-distance PtP connectivity
- Suitable for ISP and telecom deployments
Should You Buy the Ubiquiti airFiber 5U?
If you are searching for a 5GHz point-to-point wireless backhaul solution in Pakistan, the Ubiquiti airFiber 5U is designed for professional deployments that require high capacity and long-distance connectivity.
Its combination of 1.2+ Gbps throughput, 100+ km specified range, GPS synchronization, 1024QAM modulation, Gigabit Ethernet, AES encryption, and outdoor-ready construction makes it suitable for WISPs, telecom companies, enterprises, and network operators.
The AF-5U should be deployed with suitable compatible antennas and a properly engineered line-of-sight link. Actual performance will depend heavily on antenna selection, spectrum availability, interference, distance, and environmental conditions.
Frequently Asked Questions
1. What is the Ubiquiti airFiber 5U used for?
The Ubiquiti airFiber 5U is a professional 5GHz point-to-point wireless backhaul radio used to establish high-speed connections between two network locations…Read More…
2. What is the maximum throughput of the airFiber 5U?
Ubiquiti specifies 1.2+ Gbps maximum throughput for the AF-5U under its stated test and deployment conditions.
3. What is the maximum range of the Ubiquiti AF-5U?
The official specifications list a maximum range of 100+ km, depending on regulatory region and deployment conditions.
4. Does the Ubiquiti airFiber 5U support PoE?
Yes. The AF-5U supports passive Power over Ethernet and uses a 50V 1.2A Gigabit PoE adapter.
5. Is the airFiber 5U suitable for ISP networks?
Yes. The AF-5U is particularly suited to WISP, ISP, telecom, and enterprise wireless backhaul networks where long-distance and high-capacity point-to-point connectivity is required.
Key Takeaway
The Ubiquiti airFiber 5U is a professional 5GHz high-band point-to-point wireless backhaul radio designed for demanding network deployments. With 1.2+ Gbps throughput, 100+ km specified range, 1024QAM modulation, GPS synchronization, 128-bit AES encryption, Gigabit Ethernet, passive PoE, and outdoor-ready hardware, it is a strong solution for WISPs, ISPs, telecom operators, enterprises, and long-distance wireless network infrastructure.
